Plot a kernel density estimate

Source: R/plot_density.R
plot_density.Rd

Create a density plot for one or more numeric variables using kernel density estimation.

Usage

plot_density(
  data,
  x,
  facet_var = NULL,
  facet_scale = "free",
  facet_nrow = NULL,
  facet_ncol = NULL,
  color = NULL,
  fill = NULL,
  title = NULL,
  subtitle = NULL,
  xlab = NULL,
  ylab = NULL,
  caption = NULL,
  line_width = 0.1,
  line_type = "solid",
  line_color = "grey35",
  fill_color = "grey35",
  fill_alpha = 0.5,
  theme_set = theme_tscv(),
  theme_config = list(),
  ...
)

Arguments

data

A data.frame, tibble, or tsibble in long format.

x

Unquoted column in data containing numeric values.

facet_var

Optional unquoted column in data used for faceting.

facet_scale

Character value defining facet axis scaling. Common values are "free", "fixed", "free_x", and "free_y".

facet_nrow

Optional integer. Number of rows in the facet layout.

facet_ncol

Optional integer. Number of columns in the facet layout.

color

Optional unquoted column in data used to map density line and fill color.

fill

Optional unquoted column in data used to map density fill color. Currently not used directly; use color for grouped density plots.

title

Character value. Plot title.

subtitle

Character value. Plot subtitle.

xlab

Character value. Label for the x-axis.

ylab

Character value. Label for the y-axis.

caption

Character value. Plot caption.

line_width

Numeric value defining the density line width.

line_type

Character or numeric value defining the density line type.

line_color

Character value defining the density line color. Ignored when color is supplied.

fill_color

Character value defining the fill color under the density curve. Ignored when color is supplied.

fill_alpha

Numeric value between 0 and 1 defining fill transparency.

theme_set

A complete ggplot2 theme.

theme_config

A named list with additional arguments passed to ggplot2::theme().

...

Further arguments passed to ggplot2::geom_density().

Value

An object of class ggplot.

Details

plot_density() is a convenience wrapper around ggplot2::geom_density(). It is useful for comparing the distribution of values across one or more time series, models, groups, or residual sets.

The arguments x, facet_var, color, and fill are passed as unquoted column names.

If color is supplied, both line color and fill color are mapped to that variable. In this case, line_color and fill_color are ignored. If color is not supplied, all density curves use line_color and fill_color.

Missing values are removed before plotting.

Additional arguments can be passed to ggplot2::geom_density() through ..., for example adjust, bw, or kernel.

Additional theme settings can be supplied through theme_config. This should be a named list of arguments passed to ggplot2::theme().

See also

Other data visualization: plot_bar(), plot_histogram(), plot_line(), plot_point(), plot_qq(), scale_color_tscv(), scale_fill_tscv(), theme_tscv(), tscv_cols(), tscv_pal()

Examples

library(dplyr)

data <- M4_monthly_data |>
  filter(series %in% c("M23100", "M14395"))

plot_density(
  data = data,
  x = value,
  facet_var = series,
  title = "Distribution of M4 Monthly Values",
  subtitle = "Kernel density estimates by series",
  xlab = "Value",
  ylab = "Density"
)


plot_density(
  data = data,
  x = value,
  color = series,
  title = "Distribution of M4 Monthly Values",
  subtitle = "Kernel density estimates by series",
  xlab = "Value",
  ylab = "Density",
  adjust = 1.2
)
